$1,299.99 Regular price

For information on sizing please click here.
  • Features
  • Specs
  • Geometry


Take the road less traveled with the Vantage RX2, a modern and sleek road bike that can do it all.

This road bicycle comes with rack-ready mounts for touring, fender mounts for commuting, and clearance up to 44c tire for gravel and pavement riding. With a carbon sport fork and Smooth Ride Technology, you don’t have to worry about an uncomfortable ride. Modern, sleek, and bold, the Vantage RX2 was built for the road.

  • Schwinn® adventure-tuned Smooth Ride Technology (S.R.T.) aluminum endurance frame and Schwinn® carbon sport fork with disc mounts
  • Shimano® drivetrain
  • Shimano® hydraulic disc brakes
  • TranzX® ergo endurance handlebar
  • Schwinn® S1 sport ergo saddle


Frame Frame N LITENED 3 aluminum, 700c adventure tuned geometry, S.R.T. (Smooth Ride Technology) Elastomer, 12 mm x 142 mm dropout, replaceable hanger, tapered headtube

Fork Fork Schwinn carbon disc, 700c, aluminum tapered steerer, 12 mm x 100 mm thru axle

Crank Crank FSA Omega Modular MegaEXO, 46/30T

Chain Chain KMC X10

Bottom Bracket Bottom Bracket FSA MegaEXO, sealed external bearing, 68 mm

Shifters Shifters Shimano GRX ST-RX400, 20-speed

Cog Icon Rear Cog Sunrace, 10-speed, 11-34T

Front Derailleur Front Derailleur Shimano GRX FD-RX400, 31.8 mm clamp

Rear Derailleur Rear Derailleur Shimano GRX FD-RX400

Rims Rims Alex DP21, aluminum, double wall, 32H, tubeless ready

Hubs Front Hub Formula RX512, aluminum, 12 mm x 100 mm thru axle, 32H, 6-bolt

Hubs Rear Hub Formula RX142, aluminum, 12 mm x 142 mm thru axle, 32H, 6-bolt

Spokes Spokes 14G, stainless steel

Tires Tires Kenda Piedmont, 700c x 40c, wire bead

Pedal Pedals Schwinn road, nylon, toe clips and straps

Brakes Brakes Shimano GRX BR-RX400, hydraulic disc, aluminum, 160 mm rotor

Handlebar Handlebar TranzX ergo flare, double-butted aluminum, 31.8 mm clamp

Stem Stem Promax, aluminum, threadless, - 6° rise, 31.8 mm clamp

Headset Headset Threadless, IS42 / IS52, semi-cartridge bearings

Seat Post Seat Post Aluminum, 350 mm, 15 mm offset, 27.2 mm

Saddle Saddle Schwinn S1 sport, steel rails

Grips Grips Schwinn road, gel cork tape

Sizes Sizes XS,SM,MD,LG,XL


A smooth ride without the weight.


SRT utilizes an elastomer mounted between the seat stays and seat tube. With 15 millimeters of travel, SRT helps absorb bumps in the road and provides a smooth ride without sacrificing efficiency.

Reduced Fatigue

Isolating characteristics of the SRT elastomer offer a more comfortable ride in the saddle, reducing fatigue on the rider.

Reduced Weight

The elastomer absorbs bumps on the road with just a fraction of added weight to the total design, making the bicycle models that utilize SRT light and enjoyable
